Certification

The certificate is valid from 2020-11-24 until 2023-11-23 (First certification 2009). Certification ISO 9001:2015.



Download Certification as PDF



Measuring equipment:

To maintain continuously high quality for the parts to be manufactured, we use the following measuring instruments.

Upon customer request, test reports and material and hardening certificates can be provided.



Measuring machine 3D manually controlled

Broun & Sharpe Microl - Val 343 on hard-stone slab Measuring precision of 0.0050



Measuring machine CNC 3D controlled

CNC coordinate measuring equipment Mitutoyo CRYSTA – Apex S500 with controlled measuring head and scan function X = 500 mm, Y = 700 mm, Z = 400 mm



Measuring device with button on hard-stone slab

Mahr Millitron 1240 with button 1340 Measuring precision of 0.0010 mm Diameter 0 - 150 mm



Wirth profile projector

Magnification	between 10 and 50 times
Table size	200 mm x 150 mm
Measuring range	50 mm x 50 mm



Hinze rigid endoscope

Endoscope diameter	16 mm
Endoscope length	150 mm
Viewing direction	direct and 90° angle



Altimeters

Mauser KMG 800 on a hard stone plate Measuring accuracy of 0.0025	X = 1.000 mm, Y = 600 mm, Z = 800 mm
Trimos 500 on a hard stone plate Measuring accuracy of 0.0030	X = 1.000 mm, Y = 1.000 mm, Z = 500 mm
Hofmann/Grant on a hard stone plate Measuring accuracy of 0,0030	X = 1.200 mm, Y = 800 mm, Z = 600 mm



Roughness testing device

Perthen perthometer H4P



Measuring microscope

Mitutoyo 280 Table size 280 x 152



as well as various mechanical measuring devices.
